Premium 3D Welded Wire Mesh Fence Panel with Custom Sizes and Anti-Corrosion Coating
Premium 3D Welded Wire Mesh Fence Panel with Custom Sizes and Anti-Corrosion Coating
Feature
-
The high-quality low-carbon steel wire welded wire fence panel series by ZZ Group is welded through exact resistance welding process. It is the perfect solution for industrial and civil enclosures. This series is our cover 3D panel fence size panel height 1.03m-2.43m panel length 2.5m standard/customized wire diameter 4.0mm-5.0mm mesh 50×200mm, 55×200mm bend quantity 2 folds up to 4 folds according to the panel height. The items can be used with pipe posts(40x60mm/60x60mm/40x40mm), arched posts(40-60mm), round pipe posts(70x100mm/50x70mm) etc., wall thickness can be chosen from 0.8mm up to 2.0mm, post heights by usually 500mm higher than the panel. Be it standard fence mesh panels or tailored heavy-duty welded mesh panels, ZZ Group has absolute accuracy in dimensions and reliability in performance.
The welded wire fence panel is one of the key members in ZZ Group's enclosure range which includes metal wire fence panels, galvanised steel wire fence panels, mild steel wire fence panels and alloy steel wire fence panels. It is made of high quality low carbon steel wire with warp and weft lines intersection points tightly fixed by the precision welding at the same time to the surface forming a structural stable grid fence panel. The welding points are stronger and the panel is not easy to bend as a whole unit. After welding, the panel will go into surface treatment process, you can choose from electro-galvanized,hot-galvanized,PVC coating,powder spraying,oxidation blacking etc. Among them, hot-galvanized has the best anti-rust and anti-corrosion effect and is suitable for outdoor long-term exposure environment; powder spraying can select multiple colors, protective and decorative; oxidation black treatment is for black welded wire fence panels, more modern looking, and has a relative high surface hardness. Heavy-duty steel mesh fence panels are precisely welded to ensure durability and resistance to bending.
| 3D panel fence specification | ||||
| Panel height | Panel Length | Wire diameter | Mesh Size | Folds No |
| 1.03m | 2.5m or custom |
4.0mm,4.5mmm,5.0mm | 50*200mm55*200mm | 2 |
| 1.23m | 2 | |||
| 1.53m | 2 | |||
| 1.73m | 3 | |||
| 1.83m | 3/4 | |||
| 2.03m | 4 | |||
| 2.43m | 4 | |||
| Square Post | Peach Post | Round Post |
| Post OD:40*60mm/60*60mm/40*40mm | Post OD:40-60mm are available | Post OD:70*100mm/50*70mm |
| Wall thickness:1.0mm/1.2mm/1.5mm/2.0mm | Wall thickness:1.0mm/1.2mm/2.0mm | Wall thickness:0.8mm/1.0mm/1.2mm |
| Post Height: usully is higher 500mm more than panel height | ||
The ZZ Group Weld Mesh Fence Are made of high quality low carbon steel wire. The tensile strength and elongation of the wire conform to fence product norms. After welding the metal mesh fence panels provide five surface treatments under the usage situation and customer’s requirement:
1) Electro-galvanizing treatment is good for indoor application or mild corrosive environment;
2. Hot-dip galvanizing possesses a thick layer of zinc with excellent anti-rust and anti-corrosion properties, it can be used outdoors for a long time;
3. PVC coating treatment is to cover the galvanized substrate with a layer of PVC plastic, which can be used for protection as well as decoration;
4. Powder coating treatment has a rich color and good appearance and it has some weather-resistance time;
5. Oxidation blackening treatment specially for black welded wire fence panels, Modern style, high surface hardness.
Every heavy duty welded wire fence panels is What are 1"x 12"x 6' heavy duty wire fence panelsSturdily welded wire mesh, heavy-gauge welded wire fabric with excellent strength.
High Porosity and Strength of the System: The whole structure of the weld mesh fence panels is welded which makes it has good strength and durability. heavy duty welded wire fence panels are constructed to be load-bearing and enduring for applications that require the fence to be exposed to certain external force impacts without damage to the structure.
Diverse Specifications for Personalization: ZZ Group provides a comprehensive selection of the mesh size, wire diameter, panel height and length, and can be tailored for projects with different requirements of wire mesh panels for fencing.
Convenient Construction and Efficiency: wire mesh panels for fencing are made by prefabrication, and can be assembled easily on the ground with posts and connection clips, no any welding operation in the field, labor and construction time are saved greatly.
Good balance of transparency and protection: The grid fence panel’s open grid design provide good air flow and visibility with a depend physical barrier.
Cost-effective and Long-lasting: Life-span of steel mesh fence panels is long, maintenance cost is low, and material can be recycled, which makes them very economical overall.
Beautiful and Functional: The metal mesh fence panels and black welded wire fence panels have a modern and clean look that can be paired with various building styles.
Welded wire fence panels are so popular and it can be seen everywhere in garden and industrial field circle, like garden and courtyard protection, factory and plant area isolation, road and highway protecting, public building and government unit security situation enclosures, park and green land isolation, sports ground wire netting, industry garden and business bulk security. heavy duty welded wire fence panels are the best choice for high quality around fences of industrial and infrastructure projects or any other applications where they are exposed to more severe usage.
Every wire fence panel is processed with multiple quality inspection procedures to inspect welding strength, surface coating adhesion and thickness, shape size accuracy, and corrosion resistance before packing. ZZ Group has formed a comprehensive quality traceability system throughout raw material input, production process, and delivery of finished goods, making sure every batch of wire mesh panels for fencing meets the design and quality requirements.
Welded wire fence panels are packaged with protection, buffer materials separate the panel surfaces to keep from getting bumbs or scratches while in the transportation.
ZZ Group was founded in early 80s and now is based in Yangpu District, Shanghai. The registered capital is 200 million RMB. It is a comprehensive enterprise group involving steel-trading, steel processing and distribution, the operation of steel raw material, real estate development, financial investment and so on. With more than 20 subsidiaries and storage points, 6 factories, and 1500 employees, the group serves with an annual sales of steel products over 4.5 million tons and sales income more than 2.7 billion US dollars. ZZ Group is an agent of leading domestic steel mills such as Baosteel, Ansteel, Shougang Group, Benxi Steel Group, Hebei Steel Group, Jiuquan Steel Group and Liuzhou Steel Co., Ltd, also serving 40000+ enterprises like Gree, Midea, Geely, Volkswagen, Xugong and so on. The group has set up a steel processing and distribution center in shanghai and in quanzhou, with the entire line service from the supply of raw material to further processing and distribution.
