Premium Color Coated Galvalume Steel Roofing Sheet for Versatile Buildin
Premium Color Coated Galvalume Steel Roofing Sheet for Versatile Buildin
Feature
-
This item is a Color Coated Galvalume Steel Sheet for Roof. It is produced with hot-dip aluminum-zinc steel plate as the base material. After surface chemical pretreatment, double-sided coating of high performance organic paint and baking curing, then be professional cold bending processing with press rollers, it is formed to one high-end building roofing material. The main range of PROCOS product is focused on PPGL Steel Roofing Sheet, with its light weight strength, customerized colors, easy installation, earthquake and fire resistant, water-proof and long term maintaining. It can be used for roof system and interior and exterior wall cladding of industrial plants, civil construction, storage, large-span steel structures and wide variety of climate regions of the world. The color and size can be customized based on project, which is able to satisfy the aesthetic and engineering standards of different countries and regions.
The color-coated aluminum-zinc steel roof panel is a kind of high quality building metal sheet which is formed by ZZ Group according to years of experience in steel supply chain services. This product adopts the molten coating continuous process, forming a high performance coat containing 55% aluminum, 43.4% zinc and 1.6% silicon on the surface of cold rolled steel substrate. Then, on a precision coating line, it is subjected to chemical conversion film, primer coating and topcoat curing. The end product can be cold bended and roll formed into different profiled panel types to satisfy diversified architectural style and structural requirements. This product has got successful application in market of Peru and other South American countries. Based on global project experience, it is now optimized for use in the tropical, temperate, cold, and coastal salt spray environments.
(1) Superior corrosion resistance
The presence of 55% aluminum in the aluminized zinc layer makes the product have much better corrosion resistance than that of traditional galvanized steel sheet. Under the same environment, its life can be 2~6 times that of normal galvanized steel sheet. The product can be used continuously in the atmosphere of industrial, coastal fog of salt and acid rain for over 10 years, and is especially fit for application in moist and high-salt environment in southeast Asia, middle east and Africa.
(2) Light weight and high strength, easy installation
The product is lightweight, being only one-thirtieth the weight of conventional concrete roofs, which will lessen burden on the building structure and also will shorten the building period. It is also the best choice for earthquake zone (like Japan, Chile and so on) construction of lightweight steel frame.
(3) Superb high temperature and insulation performance
The heat reflection of PPGL Steel Roofing Sheet is good, which can effectively reduce the temperature of the building surface. In hot (Middle East, Africa) and cold climates, it retains its stable physical properties even under such conditions, and it is the perfect roofing sheet for tropical and sub-tropical countries.
(4) Eco-friendly and recyclable
This product is a green, environment-friendly building material, which can be recycled and reused 100%. Its adoption is a global trend and is conducive to matching national sustainable development strategies.
(5) Global flexibility in color and specifications
The color of the product is not only green. It can supply the full RAL color cards (red, blue, white, gray, orange and so on) as per customers’ requests. Thickness, width, length and wave configuration are customizable based on different national building code for a perfect match local standards.
The product consists of a five-layer: substrate (cold rolled steel plate), aluminized zinc alloy layer (55% aluminum - 43.4% zinc - 1.6% silicon), chemical conversion coating, base coating and top coating. The topcoat may be chosen from the high performance coatings systems such as PE (polyester), SMP (silicone modified polyester), HDP (high durability polyester), PVDF (polyvinylidene fluoride) and others to satisfy different environmental class and period of warranty requirements.
| Item | Specifications |
| Standard | AISI, ASTM, BS, DIN, GB, JIS |
| Grade | DX51d, G550, etc., all customizable per customer requirements |
| Color | Green color, or as customers’ requirement |
| Thickness | 0.12mm – 1.5mm, all available |
| Width | Customizable |
| Length | according to per customer's requirement |
| Alu-zinc coating | 30–150 g/m² |
| Film | 12-35um; Back: 5-25um |
| Corrugation specifications | *Raw material 762mm to 665mm(after corrugated) and 9 waves; *Raw material 914mm to 800mm-890mm(after corrugated) and 11 waves; *Raw material 1000mm to 900mm or 920mm(after corrugated) and 12 or 14 waves; *Raw material 1200mm to 1070mm(after corrugated) and 17 waves also can produce as per customer's requirement |
Both Ppgi Corrugated Sheet And PPGL Steel Roofing Sheet Have The Following Features:
High strength and low weight: The product is light in weight and high in strength, which significantly reduces the load on the structure of the building;
Color rich and customizable: Support the world's mainstream color cards, to meet personalized needs for architectural;
Easy construction: It is easy to be installed and operated, and the construction period can be greatly reduced.
Seismic and fire resistance: Good seismic performance, fire resistance rating.
Waterproof and Long-lasting: Good sealing performance and long serving life;
No Maintenance: Surface coating is compact and do not need for frequent maintenance.
Color Coated Steel Roofing Sheet is widely used in the following fields:
1.Roofs and walls of industrial and civil buildings;
2.Large-span buildings, such as the warehouses, logistics centers, e t c;
3.Public buildings for example stadiums, exhibition centers, etc.;
4.Roof and interior and exterior walls of steel home;
5.Special building works equipment shells / agricultural greenhouses, etc.;
You can tailor them to suit the projects in various climate zones across the world (ex, Southeast Asia, The Middle East, Africa, South America, Europe and so on).
| Application Areas | Typical Scenarios |
| Industrial Buildings | Roofing and walling for factory workshops, manufacturing plants, and processing centers |
| Residential Buildings | Roof and exterior wall decoration for residential communities, villas, and apartment buildings |
| Warehousing & Logistics | Large-span roofing for warehouses, logistics centers, and distribution centers |
| Public Facilities | Large venues such as gymnasiums, exhibition halls, railway/bus stations, and airports |
| Commercial Buildings | Commercial complexes including shopping malls, supermarkets, and office buildings |
| Special Buildings | Agricultural greenhouses, equipment enclosures/housings, temporary structures, etc. |
1.Preparation before installation: The acceptance of the main structure steel will finished before installation to make sure the spacing, straightness, height, anti-corrosion of the roof trusses meet the design requirement;
2.Plate Inspection: Confirm the material spec, color batch and surface quality after the steel plates received;
3.Layout and installation: Make exact layout according to the drawing to get the installation position and height;
4.Laying and fixing: According to design requirements lay the plates with lap width according to the regulation and fix with self-tapping screws;
5.Treatment of waterproof: Flashing plate or edge piece node with silicone weatherproof sealer for waterproof sealing;
6.Protection: pay attention to protect the coating during installation, no scratches no bumbs please.
Protection:
Apply several protective abstracts for moisture, rust and impact.
Shipping method:
Support multiple logistic type such as ocean shipping, land transportation and railway transportations;
Delivery scope:
With the support of ZZ Group’s 20+ subsidiaries / storage points network in every part of China, it can cover every major region in China and is capable to be shipped out to major continents efficiently through ports such as Shanghai, Tianjin and Guangzhou.
Sample specifications and color can be tailored based on requests from customers;
If you need the detail sample policy, pls get in touch with the sales person.
The ZZ Group follows the business principle of "Integrity and pragmatism, innovating and mutual benefits", carries out "Integrity" service for the customers:
An unconditional assurance for returning or exchanging the products that are of poor quality;
Professional technical teams provide installation guidance and technical support;
Long-term follow-up service, quick response to the needs of customers.
ZZ Group was founded in the early 1980s, with its head office in Shanghai. The registered capital is RMB 200 million. It is at all a whole enterprise group from steel trading, steel processing and distribution, steel raw material operation to real estate developing, financial investment and so on. It has been selected as the "Top100 Honest Enterprises in National Steel Trading and Logistics" and "Top100 Private Enterprises in Shanghai Steel Trading". It is greatly influential in the Chinese metal materials market. The group currently has more than 20 subsidiaries and storage points nationwide, the total employees more than 1,500 people. The annual trading volume of steel products exceed 4.5 million tons and the annual profit of sales exceed 2.7 billion U.S. dollars. It has the strongability of serving global customers.
Q1:What is the difference between the PPGL Steel Roofing Sheet and the PPGI Corrugated Sheet?
A1: The difference is the base plate coating. PPGI corrugated sheet is made of hot dip galvanized steel as base plate with the coating material as pure zinc; while PPGL steel roofing sheet is made of alu-zinc coated steel with the coating material of 55% alu - 43.4% Zn - 1.6% Si. The latter has better corrosion resistance, heat resistance and longer life.
Q2: Can the color of the product be customized? Not just green, right?
A2: Yes. We provide full color customisation services. You can send us your color sample, and we will make a match and produce.
Q4: What is the MOQ for the product?
A4: The MOQ may vary depending on the different specifications and colors. please contact the sales for more detail.
Q5: Does the product support customized forming (ex. corrugated shape, width)?
A5: Yes. Thickness, width, length, color etc of the products can be customized to meet customers' requirements.
Q6: How to guarantee the quality of the product during transportation?
A6: The product is packaged in standard sea transportation packaging. We also can add anti-rust films, frozen wood pallets, etc.as protection based on the shipping route to protect the products during long distance sea shipping to make sure the products are complete!
