Powder Coated Steel Fence Post for Durable Metal Fencing
Powder Coated Steel Fence Post for Durable Metal Fencing
Feature
-
Steel star picket fence posts, commonly referred to as steel Y posts, star posts, metal pickets, or steel fence posts, are widely used for supporting various fencing systems. Their unique cross-sectional design features a three-point star shape with an approximate diameter of 10 cm, providing excellent strength and stability after installation. The pointed end allows the post to be driven into the ground easily, while the flat top is designed for convenient hammering during installation. A series of pre-punched holes along the post length enables quick attachment of wires, fencing mesh, and barrier materials, making them an ideal choice for temporary fencing, security barriers, and agricultural applications.
1.Surface Finish: Available with powder coating or hot-dip galvanizing treatment to provide enhanced corrosion resistance and longer service life.
2.Available Standards: Manufactured according to various specifications, including American, Australian, and European standards to meet different market requirements.
3.Post Length: Offered in standard lengths from 0.45m to 3.0m, with customized sizes available based on specific project needs.
4.Color Options: A wide range of colors are available, including black, woodland grey, river sand, jasper, monument, domain, paperbark, manor red, and other customized coating colors.
5.Packaging: Supplied with standard seaworthy packaging to ensure safe transportation and delivery.
6.Applications: Suitable for various fencing projects, such as garden fencing, highway barriers, sports field fences, farm enclosures, and other security fencing solutions.
| Length(cm) |
45 |
60 |
90 |
135 |
150 |
165 |
180 |
210 |
240 |
| Holes(Australia) |
2 |
3 |
5 |
11 |
14 |
14 |
14 |
7 |
7 |
| Holes(New Zealand) |
7 |
7 |
7 |
8 |
|
|
0.45M |
0.60M |
0.90M |
1.35M |
1.50M |
1.65M |
1.80M |
2.10M |
2.40M |
|
SPEC |
PCS/MT |
PCS/MT |
PCS/MT |
PCS/MT |
PCS/MT |
PCS/MT |
PCS/MT |
PCS/MT |
PCS/MT |
|
2.04kg/M |
1089 |
816 |
544 |
363 |
326 |
297 |
272 |
233 |
204 |
|
1.90kg/M |
1169 |
877 |
584 |
389 |
350 |
319 |
292 |
250 |
219 |
|
1.86kg/M |
1194 |
896 |
597 |
398 |
358 |
325 |
298 |
256 |
224 |
|
1.58kg/M |
1406 |
1054 |
703 |
468 |
422 |
383 |
351 |
301 |
263 |
1. Excellent Strength & Stability
The unique Y-shaped star profile provides high structural strength and excellent load-bearing performance, helping the fence posts remain stable even under harsh outdoor conditions. The three-point design improves ground grip and reduces the risk of tilting after installation.
2. Corrosion Resistant & Long Service Life
Available with powder coating or hot-dip galvanized surface treatment, steel star picket fence posts offer strong resistance against rust, moisture, and weather damage. The durable coating helps extend service life and reduces maintenance costs.
3. Easy Installation & Labor Saving
The pointed end design allows the posts to be driven into the ground quickly and easily, while the flat top makes hammering more convenient. Pre-drilled holes along the post provide flexible options for attaching wires, mesh, and other fencing materials.
4. Multiple Standards & Custom Options
Manufactured according to American, Australian, and European standards, our steel Y posts are suitable for different market requirements. Various lengths, colors, and surface finishes can also be customized according to customer specifications.
5. Wide Range of Applications
Steel star picket fence posts are widely used in agricultural fencing, garden fencing, highway barriers, sports fencing, temporary fencing, and security protection projects, providing a reliable solution for different fencing needs.
6. Cost-Effective Fencing Solution
With high durability, simple installation, and low maintenance requirements, steel fence posts provide a practical and economical choice for both temporary and permanent fencing projects.
The durable and low-maintenance Metal Fence Post is designed for a wide range of fencing applications. With a strong three-pointed star profile and powder coated surface, these Fencing Posts Metal products provide excellent stability, corrosion resistance, and long-term performance in various environments.
1. Airport Security Fencing
Steel Y Posts are widely used for airport perimeter protection due to their high strength and reliable support capability. They help create secure boundaries while withstanding outdoor weather conditions.
2. Railway Safety Barriers
The robust structure of Powder Coated Steel Posts makes them suitable for railway fencing projects, providing stable support for wire mesh and security barriers to protect railway areas.
3. Playground & Public Area Fencing
With a neat appearance and durable coating, the Metal Fence Post is an ideal choice for playgrounds, parks, and public facilities where both safety and long service life are required.
4. Construction Site Protection
The easy installation and strong holding performance of Fencing Posts Metal make them suitable for temporary fencing around construction sites, helping improve site security and management efficiency.
5. Perimeter & Security Fencing
Designed for permanent and temporary boundary protection, Steel Y Posts offer excellent stability for residential, commercial, and industrial perimeter fencing systems.
6. Swimming Pool Safety Fencing
The corrosion-resistant Powder Coated Steel Posts are suitable for swimming pool fencing applications, providing a reliable barrier solution with minimal maintenance requirements.
7. Agricultural & Farm Fencing
The versatile design of the Metal Fence Post allows it to be used for farm boundaries, livestock fencing, and agricultural protection projects, delivering a cost-effective and long-lasting fencing solution.
1.Post Tube Specification:
The fence post should have a minimum outer diameter of 76mm, with a wall thickness of 2.9mm. For corner posts, a larger diameter of at least 160mm is required, with a wall thickness of 3.6mm to provide additional strength and stability.
2.Gate Quantity Requirement:
For a 2-kilometer chain link fence project, a total of four gates are required, including single-leaf pedestrian gates and double-leaf vehicle access gates.
3.Top Tension Bar Details:
The top tension bar should be manufactured with a diameter of 76mm, a wall thickness of 1.8mm, and a standard length of 2800mm to ensure proper fence reinforcement.
4.Corner Post Quantity:
A total of 10 corner posts are needed for a chain link fence installation covering a length of 2 kilometers.
5.Fence Height & Post Dimensions:
The required fence post length is 2650mm, with a finished fence height of 2000mm. The Y-shaped top extension arm adds an additional height of 500mm for enhanced security and protection.
